Description

DCBT-050-24-10-10, Hall Effect DC Current Transducer, +/-50 Amp DC, +/-10VDC bipolar output, 24VDC supply, 20mm Aperture

Compact and versatile Split Core DC current sensor, +/-50 Amp DC, +/-10VDC Bipolar Output

Features

  • ⌀20mm Aperture
  • DC Bipolar Measurement
  • +/-10VDC analogue output
  • Busbar, or panel mounting
  • Isolated plastic case recognised according to UL94-V0

Advantages

  • High isolation between primary and secondary circuits
  • Easy installation
  • DIN Rail Kit available

Applications

-Automation Systems

Analogue current reading for remote monitoring (e.g. Motor)

-Data Loggers

Self Powered. Will not drain data logger batteries

-Panel Meters

Simple connection displays power consumption

Specification
Fastron Part NumberDCBT-050-24-10-10
Technology DC Hall Effect Current Transducer with Instant Output
Yes
Supply Voltage24VDC
Nominal Current (RMS + DC)+/-50 Amp
Response Time< 1uS
OutputBipolar +/-10VDC Analogue
Isolation2.5kV (AC, 50Hz, 1 min)
BandwidthDC
Aperture20mm
Mounting StylePanel Mount
Operating Temperature Range-40°C / 85°C
Accuracy1%
Termination StyleMolex 4 Pin
Unit Weight120g
Factory Pack Qty6



Datasheet
