DCBT 100 24 420 Hall Effect DC Current Transducer | ±100A DC Current Sensor | 4-20mA Bipolar Output | 24VDC Power Supply | 20mm Aperture - Perfect for Solar Power Systems, EV Charging Stations & Industrial Automation

DCBT 100 24 420 Hall Effect DC Current Transducer | ±100A DC Current Sensor | 4-20mA Bipolar Output | 24VDC Power Supply | 20mm Aperture - Perfect for Solar Power Systems, EV Charging Stations & Industrial Automation

DCBT 100 24 420 Hall Effect DC Current Transducer | ±100A DC Current Sensor | 4-20mA Bipolar Output | 24VDC Power Supply | 20mm Aperture - Perfect for Solar Power Systems, EV Charging Stations & Industrial Automation

DCBT 100 24 420 Hall Effect DC Current Transducer | ±100A DC Current Sensor | 4-20mA Bipolar Output | 24VDC Power Supply | 20mm Aperture - Perfect for Solar Power Systems, EV Charging Stations & Industrial Automation

DCBT 100 24 420 Hall Effect DC Current Transducer | ±100A DC Current Sensor | 4-20mA Bipolar Output | 24VDC Power Supply | 20mm Aperture - Perfect for Solar Power Systems, EV Charging Stations & Industrial Automation

$189.75 $345 -45% OFF

Free shipping on all orders over $50

7-15 days international

27 people viewing this product right now!

30-day free returns

Secure checkout

75092773

Guranteed safe checkout

Description

DCBT-100-24-420, Hall Effect DC Current Transducer, +/-100 Amp DC, 4-20mA bipolar output, 24VDC supply, 20mm Aperture

Compact and versatile Split Core DC current sensor, +/-100 Amp DC, 4-20 mA Bipolar Output

Features

⌀20mm Aperture
DC Bipolar Measurement
4-20mA analogue output
Busbar, or panel mounting
Isolated plastic case recognised according to UL94-V0

Advantages

High isolation between primary and secondary circuits
Easy installation
DIN Rail Kit available

Applications

-Automation Systems

Analogue current reading for remote monitoring (e.g. Motor)

-Data Loggers

Self Powered. Will not drain data logger batteries

-Panel Meters

Simple connection displays power consumption

Specification

Fastron Part Number	DCBT-100-24-420
Technology	DC Hall Effect Current Transducer with Instant Output
	Yes
Supply Voltage	24VDC
Nominal Current (RMS + DC)	+/-100 Amp
Response Time	< 1uS
Output	Bipolar 4-20mA
Isolation	2.5kV (AC, 50Hz, 1 min)
Bandwidth	DC
Aperture	20mm
Mounting Style	Panel Mount
Operating Temperature Range	-40°C / 85°C
Accuracy	1%
Termination Style	Molex 4 Pin
Unit Weight	120g
Factory Pack Qty	6

Datasheet
