DR2260A20V Solid State Relay SSR - Single Phase 20A 90-280VAC Control, 48-600VAC Load, DIN Rail Mount for Industrial Automation & HVAC Systems
DR2260A20V Solid State Relay SSR - Single Phase 20A 90-280VAC Control, 48-600VAC Load, DIN Rail Mount for Industrial Automation & HVAC Systems

DR2260A20V Solid State Relay SSR - Single Phase 20A 90-280VAC Control, 48-600VAC Load, DIN Rail Mount for Industrial Automation & HVAC Systems

$69.3 $126 -45% OFF

Free shipping on all orders over $50

7-15 days international

14 people viewing this product right now!

30-day free returns

Secure checkout

11015050

Guranteed safe checkout
amex
paypal
discover
mastercard
visa
apple pay

Description

Crydom DR2260A20V, Solid State Contactor SSR, Single Phase 90-280VAC Control, 20A, 48-600VAC Load, Din Rail Mount

Features

  • Ratings from 20A to 35 Amp @ 48-660 VAC
  • Contactor Style for retrofit
  • SCR output for heavy industrial loads
  • Zero voltage or instantaneous turn-on outputs
  • UL/CSA/VDE Approved, CE Compliant to EN60950-1
  • Improved SEMS screw and washer
  • Redesigned housing with anti-rotation barriers
  • AC & DC control types
  • Direct bond copper substrate
  • EMC compliant to Level 3
  • Direct power lead frame
  • Epoxy free design
Spec
Crydom Part NumberDR2260A20V
Switching TypeZero Crossing
ROHSYes ()
Control Voltage90-280VAC
Load Current (single unit)20 Amp (rms) @ 40 Deg C Ambient, 16 Amp (rms) @ 50 Deg C Ambient
Load Current (multiple units)20 Amp (rms) @ 40 Deg C Ambient, 16 Amp (rms) @ 50 Deg C Ambient
Surge Capability 286 Amp (peak)
Special FeatureContactor Style Terminals
Mounting StyleDIN Rail Mount
Load Voltage Range48 - 660VAC
EMC CompliantLevel 3
Termination StyleScrew
Unit Weight298g
Factory Pack Qty20



Datasheet
Alternatives

SSR Style

App Notes
Heatsink
