41018784
| Dynex Part Number | DIM125PHM33-TS000 |
| Vces | 3300V |
| Transistor Configuration | Dual IGBT Module (Half Bridge) |
| Ic(nom) @ 80 Deg C | 125 Amp |
| Package Size | W:73mm L:140mm D:38mm |
| V(isol) | 6 kV |
| Vf @ 25 Deg C | 2.9V |
| Tj(max) | 150°C |
| Td(on) @ 25 Deg C | 1.18uS |
| Td(off) @ 25 Deg C | 1.95uS |
| I(ces) @ 25 Deg C | 5mA |
| Rcc | |
| Terminals | M5 Screw |
| Hole Centres | 57 x 124mm(M6) |
| Gate Terminals | Spade (A 2.8 - 0.5mm) |
| R th(j-c) | |
| R th(c-h) | |
| Weight | 750g |
| Mounting Torque | 5 Nm (4 Nm Terminals) |
| Factory Pack Qty | 10 |
| Certification | UL Listed, ROHS |
