3 Phase Half Wave Diode Bridge Rectifier DMA150YA1600NA - Common Anode, 1600V 150A, SOT 227B Package - Ideal for Industrial Power Supplies, Motor Drives & Renewable Energy Systems
3 Phase Half Wave Diode Bridge Rectifier DMA150YA1600NA - Common Anode, 1600V 150A, SOT 227B Package - Ideal for Industrial Power Supplies, Motor Drives & Renewable Energy Systems

3 Phase Half Wave Diode Bridge Rectifier DMA150YA1600NA - Common Anode, 1600V 150A, SOT 227B Package - Ideal for Industrial Power Supplies, Motor Drives & Renewable Energy Systems

$32.45 $59 -45% OFF

Free shipping on all orders over $50

7-15 days international

23 people viewing this product right now!

30-day free returns

Secure checkout

51189090

Guranteed safe checkout
amex
paypal
discover
mastercard
visa
apple pay

Description

Westcode-IXYS-Littlefuse DMA150YA1600NA, 3 Phase Half Wave Diode Bridge, Common Anode, 1600V, 150Amp, SOT-227B

Features

  • Package with DCB ceramic base plate
  • Isolation voltage 3000 V∼
  • Planar glass passivated chips
  • Low forward voltage drop
  • Leads suitable for PC board soldering
  • UL registered, E 148688

Applications

  • Heat and temperature control for industrial furnaces and chemical processes
  • Lighting control
  • Motor control
  • Power converter

Advantages

  • Easy to mount with two screws
  • Space and weight savings
  • Improved temperature and power cycling capability
  • High power density
    Specification
    Westcode-IXYS-Littlefuse Part NumberDMA150YA1600NA
    AC Line voltage533V
    Device ConfigurationThree Phase Half Wave Diode Rectifier Bridge
    DC Output @ 95 Deg C150 Amp
    Package SizeW:38mm L:25mm D:12mm (SOT-227B)
    Itsm800 A
    VF(to)0.82V
    Tj(max)150°C
    rF6.3mΩ
    TerminalsM4 (1.5Nm)
    Hole Centres32mm (M4)
    Gate TerminalsN/A
    R th(j-c) 0.6°C/W
    R th(c-h) 0.1°C/W
    Weight30g
    Isolation3kV
    Factory Pack Qty10
    CertificationUL Listed
    IXYS HeadquartersUnited States

    Datasheet

    Alternatives

    See for alternative with larger package
