DPM48I200 48mm x 96mm LED Digital DC Ammeter & Voltmeter with 150mVDC Shunt Input - 0.5% Accuracy, 40-300VAC/DC Power Supply, IP54/IP65 - Perfect for Industrial Equipment, Solar Power Systems, and Electrical Panel Monitoring
DPM48I200 48mm x 96mm LED Digital DC Ammeter & Voltmeter with 150mVDC Shunt Input - 0.5% Accuracy, 40-300VAC/DC Power Supply, IP54/IP65 - Perfect for Industrial Equipment, Solar Power Systems, and Electrical Panel Monitoring
DPM48I200 48mm x 96mm LED Digital DC Ammeter & Voltmeter with 150mVDC Shunt Input - 0.5% Accuracy, 40-300VAC/DC Power Supply, IP54/IP65 - Perfect for Industrial Equipment, Solar Power Systems, and Electrical Panel Monitoring

DPM48I200 48mm x 96mm LED Digital DC Ammeter & Voltmeter with 150mVDC Shunt Input - 0.5% Accuracy, 40-300VAC/DC Power Supply, IP54/IP65 - Perfect for Industrial Equipment, Solar Power Systems, and Electrical Panel Monitoring

$81.95 $149 -45% OFF

Free shipping on all orders over $50

7-15 days international

11 people viewing this product right now!

30-day free returns

Secure checkout

63045864

Guranteed safe checkout
amex
paypal
discover
mastercard
visa
apple pay

Description

Secure Meters DPM48I200-2, 48mm x 96mm Digital DC Ammeter, DC Voltmeter +/-150mV Shunt Input, 0.5% Accuracy, 40 to 300VAC/DC Supply, IP54 (Optional IP65)



Features

  • LED Dual Display
  • 250mS Response Time
  • PC 94 UL V0
  • Each unit needs just 96 x 48mm Panel Space
  • 52mm Depth
  • CE Approved
  • ROHS and REACH
    Specification
    Secure Part NumberDPM48I200-2
    Frequency Range45-65 Hz
    Accuracy0.5%
    Input+/-150mVDC
    Over Rangex 1.5
    Operating Temperature0 - 60°C
    Supply Voltage40-300VAC/DC
    Termination StyleScrew
    Mounting Style 96 x 48mm Panel Mount
    Case MaterialPC - UL 94 V0
    StandardsIEC / EN 61010-1; IEC / EN 61010-2-030
    Protection DegreeIP54 (IP65 Optional)
    Weight280g
    Factory Pack Qty1
