DCT 0010 050 AC Current Transformer - Self Powered 50A RMS 0-5V Output for Energy Monitoring & Industrial Applications
DCT 0010 050 AC Current Transformer - Self Powered 50A RMS 0-5V Output for Energy Monitoring & Industrial Applications

DCT 0010 050 AC Current Transformer - Self Powered 50A RMS 0-5V Output for Energy Monitoring & Industrial Applications

$75.9 $138 -45% OFF

Free shipping on all orders over $50

7-15 days international

24 people viewing this product right now!

30-day free returns

Secure checkout

81520039

Guranteed safe checkout
amex
paypal
discover
mastercard
visa
apple pay

Description

Magnelab DCT-0010-050, AC CT, Self Powered, 50 Amp Average RMS 0-5V output

Features

  • Split Core
  • 0-5V Average RMS Output
  • Cable Mounting
  • Self Powered
  • Isolated plastic case recognised according to UL94-V0

Advantages

  • Large aperture for cable up to ⌀ 16mm
  • High isolation between primary and secondary circuits
  • Easy installation

Applications

  • Current Measurement
  • Energy Management
  • Motor Control
  • Actuators
  • Lamp Failure
Specification
Magnelab Part NumberDCT-0010-050
TechnologyAC Current Transformer
Supply VoltageSelf Powered
Load Current (RMS)50 Amp
Maximum Measurement Current (RMS)75 Amp
Output0-5V (Average RMS) 5% Ripple
Response Time300ms
Isolation2.5kV (AC, 50Hz, 1 min)
Voltage RatingCat III 600VAC
Bandwidth50/60Hz
Mounting StyleCable Mount
Operating Temperature Range-20°C / 50°C
Accuracy2%
Aperture⌀ 10mm
Termination StyleScrew
ApprovalsCE,UL,ROHS2
Unit Weight70g
Factory Pack Qty6

Datasheet
